Product Summary
Specifications
 | Parametric | |
| Model | RSE-T3-75-I ~ RSE-T3-110-I | |
| Bypass Type | Inaedificata bypass genus | |
| Voltage | 380V | |
| Acta motoris virtutis (kW) | 75/90/115 | |
| Rated output current (A) | 150/180/230 | |
| Dimensiones (mm) | 443*243*248 | |
| Installation size (mm) | 392* 180 | |
Product Overview
Wiring et Terminals
Exemplar Nomenclature
Electio Tabula
| Exemplar (380V) | Acta motricium virtutis ( kW ) | Ego de (A) | Dimensiones H*W*D (mm) | Installation size (mm) | |
| H1* W1 | Apertura | ||||
| RSE-T3-7-I | 7.5 | 15 | 342* 200-208 | 299*145 | M6 |
| RSE-T3-11-I | 11 | 23 | |||
| RSE-T3-15-I | 15 | 30 | |||
| RSE-T3-18-I | 18.5 | 37 | |||
| RSE-T3-22-I | 22 | 45 | |||
| RSE-T3-30-I | 30 | 60 | |||
| RSE-T3-37-I | 37 | 75 | |||
| RSE-T3-45-I | 45 | 90 | |||
| RSE-T3-55-I | 55 | 110 | |||
| RSE-T3-75-I | 75 | 150 | 443*243*248 | 392* 180 | M8 |
| RSE-T3-90-I | 90 | 180 | |||
| RSE-T3-110-I | 115 | 230 | |||
| RSE-T3-132-I | 132 | 264 | 670* 280*248 | 588*230 | M10 |
| RSE-T3-160-I | 160 | 320 | |||
| RSE-T3-185-I | 185 | 370 | |||
| RSE-T3-200-I | 200 | 400 | |||
| RSE-T3-250-I | 250 | 500 | 710*320*252 | 628*260 | M10 |
| RSE-T3-280-I | 280 | 560 | |||
| RSE-T3-320-I | 320 | 640 | |||
Euismod & configurationis
| Characteres electrica | |
| Rated imperium potentia copia | Single-phasma 220VAC±15%, 50/60Hz |
| Rated potentia copia voltage | Three-fash 380V~ 480V (-10%~ 15%) |
| Rated potentia copia frequentia | 50Hz vel 60Hz |
| Multis imperii temporibus | 3 |
| Lorem motricium | Aeschyli cavea tres tempus inductionem motricium / asynchronous motricium |
| Satus frequency | Conditiones onus dependet. Commendatur incipere et desinere non plus quam 10 vicibus per horam sub condicionibus normalibus et 6 vicibus per hora sub onere gravi |
| Satus modus | Aggerem intentione, ramp current, modus current, inching, agger currens modus, subitus saltus voltage aggerem |
| Subsisto modus | Free stop, mollis stop |
| Munus tutelae | Praesidium amissum phase, supercurrentis tutela, oneris praesidium, inaequilibrium current praesidium, exustum praesidium, initium timeout praesidium, undervoltage/overvoltage protection, start over frequency protection, high current protection, thyristor naufragii praesidium, potentia e contrario serie praesidium, erroris praesidium, etc. |
| Environmental notae | |
| operating temperatus | -10℃ ~ 40℃ (40℃ ~ 60℃ opus est ad facultatem reducendi) |
| Repono temperatus | -25℃ ~ 70℃ |
| Relativum humiditas | XCV% nulla condensatione vel cadendo |
| altitudo | Infra 1000m (1000~3000m facultatem reducendi opus est) |
| Modus refrigerandi | 55kW and below: refrigerationem naturalem; 75kW et supra: coactus aer refrigerationem |
| modum institutionem | Murus conscendit |
| Other | Non flammabiles, explosivae, vel exedrae vapores, nullus prolixivus pulvis vel pulveris metallicus |
| Signa et Certification | |
| Exsequendam signa | GB/T14048.6 |
| Certification | CCC |
