Product Summary
| | | Remota download progressionis PLC, Vide portum et portum retis |
| | Real-time data magna, coetus procuratio | |
| | Historica notitia repono nubes, continua transmissio si disiunctio | |
| | Cloud configurationem magna, telephono mobili & PC | |
| | Terrorem informationes dis, WeChat, telephonum, SMS APP | |
| | Varii methodi tradendae: MQTT/HTTP/OPC |
Ager fabrica accumsan
In apparatu industriae situs, UBox coniungere potest cum instrumento Ruineng HMI, PLC, inverto et instrumento quodam, notitia instrumentorum ad colligendum pertinentes, connectito interreti per broadband, wifi, et 4G, et data instrumenta ad Ruineng nubem suggestum transmittere.
Nubes Data Layer
Raynen Cloud in servientibus Cloud Alibaba obsidetur, quae notitias ab UBoxes in sitibus industrialibus accipiunt. Data in on-site collecta servo, et notitia repositionis et transmissionis fiunt, data commercio inter notitias et clientes remotos.
User Layer
Fines utentes remotius possunt accedere notitiae campi industrialis per terminos PC et mobiles et operandi uncinis et instrumentis administrandi. Eodem tempore, nubes suggestus notitiarum monumentorum praebere potest analysin instrumentorum usorum ad sustentationem data.
HD Introduction
Magnitudo (unitas: mm)
Specification
| Modus | UBoxE-WAN | UBoxE-WiFi | UBoxE-4G | UBoxE-4G-3L | UBoxE-4G-GPS | UBoxE-4G-DATA | UBoxE-4G-VPN |
| Ordo numerus | UBoxE-WAN | UBoxE-WiFi | UBoxE-4G | UBoxE-4G-3L | UBoxE-4G-GPS | UBoxE-4G-DATA | UBoxE-4G-VPN |
| Euismod specifications | |||||||
| Processor | A8, 600MHz | A8, 600MHz | A8, 600MHz | R16, 1GHz | A8, 600MHz | A8, 600MHz | A8, 600MHz |
| Repono | 256MB FLASH 128MB DDR3 | ||||||
| USB Host | USB2.0 1, Typus A (USB) | N/A | |||||
| Vide interface | RJ45 COM1: RS485 COM2: RS232 COM3: RS485 | N/A | RS485/RS232/RS485 | RS485/RS232 | RS485/RS232 | ||
| Vide portum solitudo | Solitudo non support | ||||||
| Portus Network | 10/100M adaptiva, retis dual port×2 | 10/100M adaptiv3 | 10/100M adaptiv2 | ||||
| 4G | N/A | N/A | Omnes Network Access | N/A | N/A | N/A | N/A |
| wifi | N/A | Support | N/A | N/A | N/A | N/A | N/A |
| Antenna | N/A | Support (3m potator antennae) | Support (3m potator antennae) | Support (3m potator antennae) | 4G antennae GPS antenna, 3 metra | Support (3m potator antennae) | Support (3m potator antennae) |
| Specificationes electricae | |||||||
| VPN remotis download | Support | Support | Support | N/A | Support | ||
| Remota notitia magna | - | Suscipe D vivere data | N/A | ||||
| Turbato per metum dis | - | SMS / WeChat / Phone / APP | N/A | ||||
| GPS | - | N/A | Support | N/A | N/A | ||
| Specificationes electricae | |||||||
| Potentia copia | 24V DC | ||||||
| Input range | 10 ~ 28V DC | ||||||
| Virtus solitudo | Solitudo subsidia | ||||||
| Patitur potentia deficiendi | 10ms | ||||||
| Nulla resistentia | Plus 50MΩ@500VDC | ||||||
| Resistentia intentione | 500V AC 1 minute | ||||||
| Characteres structurae | |||||||
| Testa color | Albus, niger | Alba speculum nigrum | Nigrum testa nigrum Speculum | ||||
| Testa materia | Abs PC plastic | ||||||
| Dimensiones | 130 95 30 (mm) | ||||||
| modum institutionem | Vexillum rail institutionem (35mm) | ||||||
| Pondus | circiter 175g | circiter 180g | circiter 195g | circiter 195g | circiter 195g | circiter 185g | circiter 185g |
| Environmental specifications | |||||||
| operating temperatus | 0 ~ 50℃ | ||||||
| humiditas operating | 10 ~ 90% RH (nulla condensatio) | ||||||
| Repono temperature | -20 ~ 60℃ | ||||||
| Repono humidity | 10 ~ 90% RH (nulla condensatio) | ||||||
| Seismic perficientur | 10 ~ 25Hz (X, Y, Z directiones 2G/30 minuta) | ||||||
| Modus refrigerandi | Naturalis aeris refrigerationem | ||||||
